Concrete Column - T-Section

Concrete Column - T-Section

Pair of dimensioned illustrations of T-Section Concrete Column seen in elevation and plan
Description
Description

A T-shaped concrete column is a type of column that has a T-shaped cross-section. The T-shape is created by having a flange on one or both sides of the column. The flanges provide additional strength and stiffness to the column, making it more resistant to bending and buckling. T-shaped concrete columns are often used in high-rise buildings and other structures where there is a need for strong and stiff columns.

Dimensions & Sizes
Dimensions & Sizes

T-Section Concrete Columns are available with typical widths and depths between 18”-36” (45.7-91.4 cm) and typical heights from 12’-36’ (3.66-11 m). The thickness of the concrete is commonly 8” or 10” (20.3, 25.4 cm).

3D Model
3D Model
Common Questions
Common Questions
View of T-Section Concrete Column in 3D available for downloadConcrete Column - T-Section
Details
Details

*Under Development*

Height:
12’-36’ | 3.66-11 m (Typical); 80’ | 24.4 m (Max)
Width:
18”-36” | 45.7-91.4 cm
Depth:
18”-36” | 45.7-91.4 cm
Length:
:
:
Weight:
Area:
:

Thickness: 8”, 10” | 20.3, 25.4 cm

Materials:
Reinforced concrete
:
:

Drawings include:

T-Section Concrete Column plan (various sizes), elevation

Concrete columns are vertical structural elements made from reinforced concrete, designed to support and transfer loads to a building's foundation. They combine steel reinforcement bars (rebar) with concrete, offering excellent strength and durability.

12’-36’ | 3.66-11 m (Typical); 80’ | 24.4 m (Max)
8”-36” | 20.3–91.4 cm (Typical); 48” | 122 cm (Max)
8”-36” | 20.3–91.4 cm (Typical); 48” | 122 cm (Max)
