Skylight - Flat

Skylight - Flat

Pair of dimensioned illustrations of the Flat Skylight seen in elevation and plan
Description
Description

A flat skylight is a type of skylight that is installed flush with the roof or ceiling surface. They are often used in buildings with flat roofs or low-pitched roofs where traditional vertical windows are not practical. Flat skylights can be designed in a variety of shapes and sizes, including square, rectangular, and circular.

They are typically made from materials such as glass, acrylic, or polycarbonate and can be either fixed or operable for ventilation. Flat skylights can improve the energy efficiency of a building by allowing natural light to enter and reducing the need for artificial lighting during the day. They can also provide a unique architectural feature to the building.

Dimensions & Sizes
Dimensions & Sizes

The Flat Skylight is available in a range of sizes with widths between 1’4”-4’ (40.6-121.9 cm), heights ranging from 3’-7’6” (91.4-228.6 cm), and an overall deck mount depth of 3” (7.6 cm). The installed roof angle for the Flat Skylight is between 14-85 degrees.

Set of drawings of the Flat Skylight in front views with a range of sizes
Set of drawings of the Flat Skylight in front views with a range of sizes
3D Model
3D Model
Details
Details

*Under Development*

Height:
3’-7’6” | 91.4-228.6 cm
Width:
1’4”-4’ | 40.6-121.9 cm
Depth:
3” | 7.6 cm
Length:
:
:
Weight:
Area:
:

Roof Angle: 14-85 degrees

Materials:
Aluminum, tempered glass
:
:

Drawings include:

Flat Skylight front elevation (various sizes), side view, plan views
