Stair Tread - Nosing, Cushion

Stair Tread - Nosing, Cushion

Set of scaled dimensioned drawings of Cushion Nosing Stair Tread viewed from the side
Description
Description

Cushion stair tread nosings, in this context, refer to a small protruding wooden nose profile affixed to the edge of each stair tread. Despite the name "cushion," these nosings are made of wood, maintaining a consistent aesthetic with the staircase. The protruding nosing enhances the stair's profile and increases safety by providing a clearer indication of the tread edge, reducing the risk of missteps.

Beyond practicality, it adds an appealing detail to the stair design, accentuating each tread. These cushion nosings thus merge safety, functionality, and style, enriching the staircase's overall appearance while promoting safer use.

Dimensions & Sizes
Dimensions & Sizes

Cushion Nosing Stair Treads are constructed with typical stair tread thicknesses between 1”-1.5” (2.5-3.8 cm).

Stair treads have a minimum allowable depth of 11” (28 cm) with riser heights between 4”-7” (10-18 cm). Stair nosings can protrude between 1”-1.5” (2.5-3.8 cm) with a maximum riser angle of 30 degrees.

Group of illustrations of Cushion Nosing Stair Tread as a full stair run
Group of illustrations of Cushion Nosing Stair Tread as a full stair run
3D Model
3D Model
Details
Details

*Under Development*

Height:
4”-7” | 10-18 cm (Riser)
Width:
36” | 91 cm (Typical)
Depth:
11” | 28 cm (Tread Minimum)
Length:
:
:
Weight:
Area:
:

Tread Thickness: 1”-1.5” | 2.5-3.8 cm


Materials:
Wood
:
:

Drawings include:

Cushion Nosing Stair Tread elevation, plan, front
