CMU - Chimney Block, Circle

CMU - Chimney Block, Circle

Scaled set of drawings of the Circle Chimney Block CMU in front, side and top views
Description
Description

A chimney CMU block with a circle core is a concrete masonry unit that has a hollow core in the shape of a circle. This core is used to create a chimney flue, which allows smoke and gases to safely escape from a fireplace or wood stove. Chimney CMU blocks with circle cores are typically used in the construction of masonry chimneys, but they can also be used in other applications where a chimney flue is needed, such as in the construction of outdoor fireplaces or pizza ovens.

Dimensions & Sizes
Dimensions & Sizes

Circle Chimney Block CMU block has a nominal depth of 16”, nominal height of 8”, and nominal width of 16”. The actual dimensions of the Circle Chimney Block CMU block include depth of 15.625” (39.7 cm), height of 7.625” (19.4 cm), and width of 15.625” (39.7 cm).

Series of illustrations of the Circle Chimney Block CMU as a wall in plan and elevation
Series of illustrations of the Circle Chimney Block CMU as a wall in plan and elevation
3D Model
3D Model
Details
Details

*Under Development*

Height:
7.625” | 19.4 cm
Width:
15.625” | 39.7 cm
Depth:
15.625” | 39.7 cm
Length:
:
:
Weight:
Area:
:

Nominal Depths: 16”

Nominal Height: 8”

Nominal Width: 16”

Mortar Joints: .375” | 9.5 mm

Materials:
Portland cement, stone aggregates
:
:

Drawings include:

Circle Chimney Block CMU front elevation, side, plan (various sizes)

Updated on
