Edison Pull Handle Dimensions & Drawings

Scale illustration of the Edison Pull Handle compared to other pull door handles

Description

The way the Edison Pull Handle offsets on one end makes it look chic and expensive. It was designed by Sergio Mazza and Giuliana Gramigna and is made of brass. The parts are round. In addition, it is of perfect size (not too small and not too large).

Dimensions & Sizes

The Edison Pull Handle has a width of 1.89” (48 mm), height of 8.78” (223 mm), and depth of 2.87” (73 mm).

Pair of dimensioned illustrations of the Edison Pull Handle seen from the top and elevation views

Description

Dimensions & Sizes

The Edison Pull Handle has a width of 1.89” (48 mm), height of 8.78” (223 mm), and depth of 2.87” (73 mm).

Door Hand Conventions

Elevation and top view drawings of the various Edison Pull Handle configurations with doors

3D Model

Under Development

Height:

8.78” | 223 mm

Width:

1.89” | 48 mm

Depth:

2.87” | 73 mm

Length:

Overall Height:

Weight:

Area:

Materials:

Brass

Designer:

Mazza & Gramigna

Year:

1968

Drawings include: 
Edison Pull Handle front elevation, side, plan, door views (front, side, plan)
