IKEA Algot Wall Upright System - 50” - Short

Set of dimensioned drawings of the IKEA Algot Wall Upright System (50” - Short) labeled with height, width, and depth

The IKEA Algot Wall Upright System (50’’ – Short) is a versatile form of wall mounted storage. This upright system option is short in height, but it is wider than other system options. Its design incorporates 6 shelves, 3 wall uprights, and 9 brackets. It is great to be stacked over other furniture.

The IKEA Algot Wall Upright System (50” - Short) has an overall system width of 50” (127 cm), height of 33.5” (85.1 cm), and shelf depth of 16.125” (41 cm).

Details

*Under Development*

Height:
33.5” | 85.1 cm
Width:
50” | 127 cm
Depth:
16.125” | 41 cm
Length:
:
:
Weight:
Materials:
Galvanized steel uprights and brackets; particleboard shelves
Designer:
Francis Cayouette (IKEA)
:

Properties

Drawings include:
IKEA Algot Wall Upright System (50” - Short) front elevation, side, plan
