Lotus Lift-Up Pull Handle

Lotus Lift-Up Pull Handle

Set of scaled dimensioned drawings of the Lotus Lift-Up Pull Handle viewed from the front, top and side
Description
Description

What you will love in the Lotus Lift-Up Pull Handle is the way the front surface of the lever is slim, almost resembling a blade, straightforward design, generous size, and sharp edges. It was designed by Javier Lopez and made of brass. The parts are round.

Dimensions & Sizes
Dimensions & Sizes

The Lotus Lift-Up Pull Handle has a width of 1.46” (37 mm), height of 9.84” (250 mm), and depth of 3.03” (77 mm). The combined overall height of the Lotus Lift-Up Pull Handle is 11.42” (290 mm).

Collection of top and elevation view drawings of the Lotus Lift-Up Pull Handle with doors
Collection of top and elevation view drawings of the Lotus Lift-Up Pull Handle with doors
3D Model
3D Model
Common Questions
Common Questions
Perspective view of a 3D model of a Lotus Lift-Up Pull HandleLotus Lift-Up Pull Handle
Details
Details

*Under Development*

Height:
9.84” | 250 mm
Width:
1.46” | 37 mm
Depth:
3.03” | 77 mm
Length:
Overall Height:
11.42” | 290 mm
:
Weight:
Area:
:
Materials:
Brass
Designer:
Javier Lopez
Year:
2014

Drawings include:

Lotus Lift-Up Pull Handle front elevation, side, plan, door views (front, side, plan)
