Pocket Door - Double, Solid, Vertical, 4 Panels

Pocket Door - Double, Solid, Vertical, 4 Panels

Pair of dimensioned illustrations of the Solid 4 Panel Vertical Double Pocket Door seen in elevation and plan
Description
Description

A double pocket door system with doors featuring 4 vertical panels is a type of door that consists of two panels, each with two rows of two vertical panels of glass or solid material. The panels are arranged in a grid pattern, with two panels on top of two panels, creating a 2x2 design. The panels are usually made of tempered or laminated glass, or solid wood or composite material, providing both durability and style.

The double pocket door design allows the doors to slide seamlessly into a pocket in the wall, creating an unobstructed opening and saving floor space. This type of door is often used in modern homes to create a sleek and minimalist look, while still allowing natural light to flow through the different spaces. The 2x2 panel design adds a unique touch to the room and makes them an attractive option for bedrooms, living rooms, and dining areas.

Dimensions & Sizes
Dimensions & Sizes

Solid 4 Panel Vertical Double Pocket Doors are available in a range of door sizes with widths between 27”-36” (69-91 cm), typical height of 6’8” (2.04 m), and depth of 1.375” (3.5 cm). The overall installed width of the double sliding door system is between 9’-12’ (2.74-3.66 m), with a height of 7’ (2.13 m), and pocket cavity depth of 2.2”-3.1” (5.5-8 cm). Door openings are between 51”-69” (1.3-1.75 m).

Set of drawings of the Solid 4 Panel Vertical Double Pocket Door in front views with a range of sizes
Set of drawings of the Solid 4 Panel Vertical Double Pocket Door in front views with a range of sizes
3D Model
3D Model
Common Questions
Common Questions
View of a Solid 4 Panel Vertical Double Pocket Door in 3D available for downloadPocket Door - Double, Solid, Vertical, 4 Panels
Details
Details

*Under Development*

Height:
7’ | 2.13 m (System)
Width:
9’-12’ | 2.74-3.66 m (System)
Depth:
2.2”-3.1” | 5.5-8 cm (Cavity)
Length:
:
:
Weight:
Area:
:

Door Panel (Height): 6’8” | 2.04 m

Door Panel (Width): 27”-36” | 69-91 cm

Door Panel (Depth): 1.375” | 3.5 cm

Door Opening (Width): 51”-69” | 1.3-1.75 m

Materials:
Wood or fibreboard door; steel rail
:
:

Drawings include:

Solid 4 Panel Vertical Double Pocket Door front elevation (various sizes), side view, plan views

Pocket doors are space-saving, sliding doors that disappear into a compartment, or "pocket," within the adjacent wall when fully opened. They operate on a top-mounted track and glide smoothly along it, eliminating the need for a floor track. Rollers or guides maintain stability.
