TOTO Flotation Drop-in 1700

TOTO Flotation Drop-in 1700

Set of dimensioned drawings of the TOTO Flotation Drop-in 1700 labeled with height, width, and depth in plan and elevation
Description
Description

The TOTO Flotation Drop-in 1700 features a pearl white color/material construction with a headrest designed to support the weight of a bather's head. The product is designed with a natural S-curve to conform with a user's spine and to provide tranquility during use.

Dimensions & Sizes
Dimensions & Sizes

The TOTO Flotation Drop-in 1700 has an overall height of 22.0625” (56 cm), length of 66.9375” (170 cm), width of 29.5” (74.9 cm), and total depth of 17.7” (45 cm).

Bathtub side clearances are recommended to maintain a consistent width of 30” (76 cm), with comfortable clearances set at around 44” (112 cm) and extremely minimal widths at 22” (56 cm).

3D Model
3D Model
Details
Details

*Under Development*

Height:
22.0625” | 56 cm
Width:
29.5” | 74.9 cm
Depth:
17.7” | 45 cm
Length:
66.9375” | 170 cm
:
:
Weight:
Area:
:

Water Depth: 15.5” | 39.4 cm
Volume: 54 gal | 204 L

Materials:
Pearl
Designer:
TOTO
:

Drawings include:
TOTO Flotation Drop-in 1700 front elevation, side, plan
