Atena Door Handle

Atena Door Handle

Set of scaled dimensioned drawings of the Atena Door Handle viewed from the front and top without locks
Description
Description

The timeless expression of the Atena Door Handle makes it look really expensive. This comes from the repeated ligne linear pattern on the handle. This engraving encourages a firm grip on the handle when opening or closing a door. It is made of brass and the parts are round.

Dimensions & Sizes
Dimensions & Sizes

The Atena Door Handle has a width of 5.28” (134 mm), height of .75” (19 mm), and depth of 2.13” (54 mm). The rosette options to pair with the Atena Door Handle include circle, vertical oval, and horizontal oval plate.

Accessible reach ranges from a maximum of 54” (137 cm) to a lower point 15” (38 cm) from the floor.

Collection of top and elevation view drawings of the Atena Door Handle with doors
Collection of top and elevation view drawings of the Atena Door Handle with doors
3D Model
3D Model
Details
Details

*Under Development*

Height:
.75” | 19 mm
Width:
5.28” | 134 mm
Depth:
2.13” | 54 mm
Length:
:
:
Weight:
Area:
:

Rosette Options: Circle, vertical oval, horizontal oval plate

Materials:
Brass
Designer:
Studio Olivari
Year:
2016

Drawings include:

Atena Door Handle front elevation, plan view, door views (front, plan)
