Icona Door Handle

Icona Door Handle

Set of scaled dimensioned drawings of the Icona Door Handle viewed from the front and top without locks
Description
Description

The Icona Door Handle has a design and finish that cuts between contemporary and modern. The lever is flat and broad, while other parts are round. This contrast creates an unexpected effect besides being pleasant to touch. It was designed by Vincent Van Duysen.

Dimensions & Sizes
Dimensions & Sizes

The Icona Door Handle has a width of 5.2” (132 mm), height of .87” (22 mm), and depth of 1.93” (49 mm). The rosette options to pair with the Icona Door Handle include circle and vertical oval.

Accessible reach ranges from a maximum of 54” (137 cm) to a lower point 15” (38 cm) from the floor.

Collection of top and elevation view drawings of the Icona Door Handle with doors
Collection of top and elevation view drawings of the Icona Door Handle with doors
3D Model
3D Model
Details
Details

*Under Development*

Height:
.87” | 22 mm
Width:
5.2” | 132 mm
Depth:
1.93” | 49 mm
Length:
:
:
Weight:
Area:
:

Rosette Options: Circle, vertical oval

Materials:
Brass
Designer:
Vincent Van Duysen
Year:
2018

Drawings include:

Icona Door Handle front elevation, plan view, door views (front, plan)
