Stone Masonry - Coursed Ashlar

Stone Masonry - Coursed Ashlar

Scaled set of drawings of Coursed Ashlar Stone Masonry in front view with dimensions
Description
Description

Coursed ashlar stone masonry is a construction type built from tooled and dressed ashlar stones with uniform properties throughout. High in cost, labor, and material waste caused by the tooling processes, coursed ashlar masonry is laid with equal heights and joints between every consecutive layer of construction. This type of masonry is very strong and durable, and it is often used in buildings that require a high level of strength and durability, such as castles, cathedrals, and other important structures. Coursed ashlar masonry is also very attractive, and it can be used to create a variety of decorative effects.

Dimensions & Sizes
Dimensions & Sizes

Coursed Ashlar Stone Masonry is comprised of stones with typical stone lengths between 5.5”-20.5” (14-52.1 cm) and stone heights of 2.25”-8” (5.7-20.3 cm). Stone masonry walls have common wall depths of 12”-24” (30.5-61 cm), typical wall heights between 5’-15’ (1.5-4.6 m), and maximum heights of around 35’ (10.7 m).

3D Model
3D Model
Common Questions
Common Questions
3D model of Coursed Ashlar Stone Masonry viewed in perspectiveStone Masonry - Coursed Ashlar
Details
Details

*Under Development*

Height:
2.25”-8” | 5.7-20.3 cm (Stone)
Width:
5.5”-20.5” | 14-52.1 cm (Stone)
Depth:
12”-24” | 30.5-61 cm (Wall)
Length:
Wall Height:
5’-15’ | 1.5-4.6 m (Typical); 35’ | 10.7 m (Max)
:
Weight:
Area:
:
Materials:
Finely cut and dressed stones
:
:

Drawings include:

Coursed Ashlar Stone Masonry elevation, plan, section

Ad Blocker
Enjoy free drawings? We do too!
Advertising helps fund our work.
Please support the project by disabling
or whitelisting your ad blocker while browsing Dimensions.Guide. Thanks!

Stone masonry is a form of construction using natural stone and mortar to make load-bearing and non-bearing walls. Stone masonry types are distinguished by how tooled the stones are and whether the stones are laid in consistent mortared horizontal courses or organized in random or uncoursed ways.
