Galley Two Row Laundry Room - Two Unit Layout

Plan and elevation drawings of a Two Row Galley laundry room with Two Units measuring widths, heights, and depths

The Galley Two Row (Two Unit) Laundry Room features a washer and dryer on one row and the other row, cabinets, beaded inset cabinets, and granite countertops. This layout makes it look squeezed, so to find space for folding and drying, you can stack the dryer on top of the washer.

The Galley Two Row Laundry Room (2 Unit) layout has a typical width of 5’ (1.52 m) and depth of 8’ (2.44 m) for an overall area of 40 ft2 (3.72 m2). A countertop height of 42” (107 cm) with a minimum work zone width of 36” (91 cm) is often used.

Details

*Under Development*

Height:
8’ | 2.44 m
Width:
5’ | 1.52 m
Depth:
8’ | 2.44 m
Length:
:
:
Weight:
Area:
40 ft2 | 3.72 m2
Units:
2

Work Zone Width: 36” | 91 cm
Counter Height: 42” | 107 cm
Counter Depth: 24” | 61 cm
Cabinet Height: 24” | 61 cm

:
:
:

Properties

Drawings include:
Galley Two Row - Two Unit Laundry Room plan, elevation

Related Collections

Ad Blocker
Enjoy free drawings? We do too!
Advertising helps fund our work.
Please support the project by disabling
or whitelisting your ad blocker while browsing Dimensions.Guide. Thanks!

Laundry rooms are utility rooms designed specifically for washing clothing. Providing adequate space for laundry machines and additional ancillary spaces for laundry storage and organization, laundry rooms may also include a sink, ironing board, cabinets, and countertops for folding clean clothing.
